HONDA Elysion 2024 2.0L e:HEV Classic MPV
| Basic information | |
| Brand name | HONDA |
| Model | Elysion 2024 2.0L e:HEV classic version |
| LEVEL | Medium MPV |
| Power Type | Hybrid |
| Emission standard | Euro Ⅵ |
| Maximum power(kW) | 158 |
| Transmission | E-CVT continuously variable transmission |
| Body structure | 5-door, 7-seater MPV |
| Engine | 2.0L 146hp L4 |
| Motor(Ps) | 184 |
| Length*width*height (mm) | 4951*1842*1711 |
| Maximum speed (km/h) | 160 |
| WLTC comprehensive fuel consumption (L/100km) | 6.17 |
| Curb weight (kg) | 1941 |
| Maximum full load mass (kg) | 2514 |
| Body | |
| Length(mm) | 4951 |
| Width(mm) | 1842 |
| Height(mm) | 1711 |
| Wheelbase(mm) | 2900 |
| Front wheel track(mm) | 1560 |
| Rear wheel track(mm) | 1560 |
| Minimum ground clearance with full load (mm) | 124 |
| Approach angle | 14 |
| Departure angle | 17 |
| Minimum turning radius | 5.4 |
| Body structure | MPV |
| Car door opening method | Swing door + sliding door |
| Number of doors (number) | 5 |
| Number of seats (seats) | 7 |
| Fuel tank volume (L) | 50 |
| Engine | |
| Engine model | LFB12 |
| Displacement (mL) | 1993 |
| Displacement (L) | 2.0 |
| Intake form | naturally aspirated |
| Engine layout | horizontal |
| Cylinder arrangement | L |
| Number of cylinders | 4 |
| Number of valves per cylinder | 4 |
| Compression ratio | 13.5 |
| Valve distributing mechanism | DOHC |
| Total engine power (kW) | 146 |
| Total engine horsepower (Ps) | 107 |
| Maximum power speed (rpm) | 6200 |
| Maximum torque(N-m) | 175 |
| Maximum torque speed (rpm) | 3500 |
| Maximum net power (kW) | 107 |
| Engine specific technology | i-VTEC |
| Energy type | Hybrid |
| Fuel grade | 92# |
| Fuel supply method | Multi-point EFI |
| Cylinder head material | Aluminum alloy |
| Cylinder material | Aluminum alloy |
| Emission standard | Euro Ⅵ |
| Electric Motor | |
| Total motor power (kW) | 135 |
| Total motor horsepower (Ps) | 184 |
| Total motor torque (N-m) | 315 |
| Maximum power of front motor (kW) | 135 |
| Maximum torque of front motor (N-m) | 315 |
| System comprehensive power (kW) | 158 |
| System comprehensive torque (N·m) | 215 |
| Number of drive motors | Single motor |
| Motor layout | Front |
| Battery Type | Lithium-ion battery |
| Transmission | |
| Abbreviation | E-CVT continuously variable transmission |
| Number of gears | Continuously variable transmission |
| Gearbox type | Electronic continuously variable transmission (E-CVT） |
| Chassis steering | |
| Drive mode | Front-engine Front-drive |
| Front suspension type | MacPherson independent suspension |
| Rear suspension type | Torsion beam non-independent suspension |
| Assist type | Electric assist |
| Body structure | Load-bearing |
| Wheel brake | |
| Front brake type | Ventilated disc |
| Rear brake type | Disc |
| Parking brake type | Electronic parking |
| Front tire specification | 225/50 R18 |
| Rear tire specification | 225/50 R18 |
